VA4N3100
The Vertiv™ Geist™ Rack Transfer Switch (RTS) VA4N3100 delivers redundant power to single corded devices. It is a 30A, 208V single phase, unit level monitored rPDU with 1 NEMA L6-30R outlet and dual input L6-30P plugs providing 4.9kW in max power capacity. It provides redundant power to single corded devices and ensures continuity in the event of power loss. It can detect power loss on the main source and automatically switch it to the secondary source in less than 4 to 8 milliseconds.
- Banking, Financial and Insurance
- Data Center/Colocation/Hosting
- Education
- Government
- Healthcare
- Military, Defense, Aerospace and Missile
- Telecom
- Retail and Wholesale
Benefits
Features
Specifications
The Vertiv™ Geist™ Rack Transfer Switch (RTS) is a versatile rack power distribution (rPDU) that provides redundant power to single corded devices. The RTS automatically detects the loss of power and switches the load to the secondary power source in 4-8 milliseconds without the need for human intervention. It helps ensure your critical equipment remains powered even in the event of a power failure.
- Product Overview
- Capacity
- 4.9Kw (208V)
- Input Voltage
- 200-240V
- Output Voltage
- 208V
- Output Options
- (1) NEMA L6-30R
- Location
- Rack
- Power Description
- Frequency
- 50/60Hz
- Interfaces/Ports
- Protocols
- DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+
- Management
- Listings
- RoHS Compliant, FCC Part 15 Class A Compliance, UL Listed 62368
- Operational Conditions
- Operating Temperature
- 60C / 140F
- Physical Characteristics
- Weight
- 19 lbs
- Weight
- 8.62 kgs
- Height
- 1.72 in
- Height
- 44 mm
- Width
- 17 in
- Width
- 432 mm
- Depth
- 18 in
- Depth
- 457 mm
