Liebert NXL
Provides reliable power protection and advanced technology for high power applications. Offers excellent dynamic performance, with the ability to handle virtually any input condition while still providing computer grade output to critical loads.
- Banking Financial and Insurance
- Data CenterColocationHosting
- Education
- Government
- Healthcare
- Retail and Wholesale
사양
Liebert NXL™ uninterruptible power supply (UPS) provides reliable data center power protection and advanced technology for high power applications. This UPS adds dynamic performance to data center design, handling virtually any input condition while still providing computer-grade output to critical loads. The Liebert NXL UPS is available in both single module and multi-module systems. Capacities include 250, 300, 400, 500, 625, 750, and 1100 kVA. Unity Power Factor as well as 0.9 PF load ratings are available. Voltages include 480, 575, and 600. Matching battery cabinets and maintenance bypass cabinets provide a complete power protection solution.
UPS protection for medium and large facilities Single and multi-module systems with latest generation technology Color touch-screen controls Matching battery cabinets and maintenance bypass cabinet
|
NXL 1100 kVA
|
||||||||
|---|---|---|---|---|---|---|---|---|
| 1100 kW | 480 / 575 / 600 Volts | 480 / 575 / 600 Volts | Up to 94% | 3 or 4 wire | 78.7 in | 228.3 in | 47.2 in | 21,800 lbs |
| 더 많은 제품 정보 보기 | ||||||||
|
NXL 800 kVA
|
||||||||
| 800 kW | 480 Volts | 480 Volts | Up to 94% | 3 or 4 wire | 78.7 | 184.8 | 47.2 | 16,120 |
| 더 많은 제품 정보 보기 | ||||||||
|
NXL 250-400 kVA
|
||||||||
| 225-360 kW | 480 / 575 / 600 Volts | 480 / 575 / 600 Volts | Up to 94% | 3 or 4 wire | 76.8 | 78.5 | 33.5 | 3965 - 5250 |
| 더 많은 제품 정보 보기 | ||||||||
|
NXL 625 kVA / 562.5 kW
|
||||||||
| 562.5 kW | 480 Volts | 480 Volts | Up to 92% | 3 or 4 wire | 76.8 | 140.5 | 39.4 | 13,200 |
| 더 많은 제품 정보 보기 | ||||||||
|
NXL 750 kVA / 675 kW
|
||||||||
| 675 kW | 480 / 575 / 600 Volts | 480 / 575 / 600 Volts | Up to 92% | 3 or 4 wire | 76.8 | 140.5 | 39.4 | 13,200 |
| 더 많은 제품 정보 보기 | ||||||||
|
NXL 625 kVA
|
||||||||
| 625 kW | 480 / 575 / 600 Volts | 480 / 575 / 600 Volts | Up to 92% | 3 or 4 wire | 76.8 | 140.5 | 39.4 | 13,200 |
| 더 많은 제품 정보 보기 | ||||||||
|
NXL 500 kVA / 450 kW
|
||||||||
| 450 kW | 480 Volts | 480 Volts | Up to 92% | 3 or 4 wire | 76.8 | 111.6 | 39.4 | 9450 |
| 더 많은 제품 정보 보기 |
복지
특징
- Liebert® NXL Operation and Maintenance Manual (SL-25425)
- Liebert® Large System 3-Phase UPS Battery System Installation Manual (SL-25418)
- Liebert® NXL System Control Cabinet Operation Manual (SL-25514)
- Liebert® Battery Interface Box Product Specs/Installation Sheet (SL-25515)
- Liebert® NXL Power-Tie Controls Installation Manual
- Liebert® NXL Power-Tie Controls Manual (SL-25521)
*모델별 다운로드를 보려면 위 사양 차트에서 모델명을 선택하여 모델별 제품 페이지로 가야 합니다.
