PSI5-800RT120
Saved This Product to Your Dashboard
You just saved this product to your dashboard to view at a later time. You can easily remove the item from your dashboard when you no longer wish to have it saved.
Please login or create an account to save this for later
PSI5-800RT120
Warranty: Vertiv backs all Vertiv™ Liebert® PSI5 UPS systems with two-year, full unit coverage, including the battery. The Vertiv no-hassle, advanced replacement warranty covers all shipping fees and includes next-day delivery, which ensures customers will receive their replacement UPS prior to returning their damaged unit with no questions asked.Benefits
Features
and power management capability — Local USB or SNMP via optional Vertiv™ Liebert® UNITY communication card
Specifications
The flexible design of the Liebert® PSI5 allows the UPS to be tower (MT models), 1U rack mountable (1U models), or to be configured as a self-standing tower or to be rack-mounted within a 2U space (RT models). It is available from 750VA to 5000VA with both 120V or 208V models. The Liebert PSI5 UPS features an innovative advanced line-interactive design incorporating buck/boost Automatic Voltage Regulation (AVR) technology. This protects against utility voltage fluctuation by raising and lowering utility power to the level needed by the connected equipment. It also allows the UPS to prolong battery life by maximizing its time on utility power before going to battery. Not for sale in Vermont, Colorado, Washington.
- Product Overview
- Power Rating
- 800VA / 720W
- Input Voltage
- Nominal: 120VAC / Range: 75-146VAC
- Output Voltage
- 120VAC (100/110/115/125VAC user-configurable)
- Efficiency
- Up to 96% (Normal Mode)
- Wiring
- Input: 5-15P; Output: 6 x 5-15R
- Miscellaneous
- Listings
- UL 1778, c-UL-us Listed, NOM, FCC Part 15, Class B
- Topology
- Line-interactive (automatic voltage regulation)
*To see model-specific downloads, you will need to go to the model-specific product page by selecting the model name in the specifications chart above.
Find Your Area Contact
Products Support Contacts
Change
Additional Resources
How Do You Select a UPS for Power Backup?
Your specific needs should determine your IT power decision. Selecting a UPS for your particular application requires an examination of a number of factors. The load size, location and criticality of the equipment to be protected are key, as well budgetary considerations, when choosing a UPS for power backup.
Power Continuity Services Selector: Renew and Maintain Your Vertiv Single-Phase UPS Population
Power Continuity Services offers flexible and complete lifecycle power renewal options for Liebert® GXT and Liebert® PSI UPS systems. This comprehensive program ranges from customer battery replacement to full-service replacement of battery and UPS with service contracts. Utilize this selector to identify what options are available for your equipment.
